Max. Capacity 50 kN
. Force : gf, kgf, Ibf, N, kN, ozf, tonf(Sl), ton(long), tonf(short)
Unit Pressure : Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force Resolution 1/50,000 (31 bits)
Force Precision +/-1% (within 2%-100% of load cell capacity; higher accuracy is optional)
Test Stroke (w/o grips) 1100 mm
Stroke Resolution 0.0001 mm
Space Between Columns 420mm (550mm ‘ 680mm ‘ 800mm are optional.)
Speed Range 0.2 ~ 600.0 mm/min
Speed Precision :t1%
PC-Port RJ45 (TCP/IP) [Software is optional]
Data Sampling Rate Max. 400 Hz
Motor Servo Motor
Machine Stiffness 53.10 kN/mm
Hardware Safety Protection Upper/Lower limit, Emergency Stop Button
Software Safety Protection Force, Displacement, Time Protection
Power Single Phase 200 ~ 240VAC ’ 8A
Dimension 90 x 60 x 195 cm
Weight 280 kg
