● Designed pressure: 0.26Mpa.
● Designed temperature: 150°C.
● Rated working pressure: 0.22Mpa.
● Sterilization temperature: 105°C-136°C.
● Sterilization time range: 0-99min.
● Material of chamber: SUS 304
● Accessories: stainless steel sterilization baskets 2
● Process, temperature, time dynamic LCD displayed, Fault automatic displayed
and alarm.
● Positive pressure pulse function exhaust cool air of chamber thoroughly
● Horizontal sliding door, self- bulge seal ring.
operated easily.
● Printer is available
for optional
Chamber size:Ø385xL495mm
External size: 616x476x990 mm,65kg
220V/50Hz4.2Kw
