* Measurement ranges :
60000 uΩ , 600 mΩ 6000 mΩ 60000 mΩ
600Ω, 6000Ω
* Test current :
10 A, 1 A, 100 mA, 10 mA, 1 mA, 100 uA.
* 4 wires with 2 Kelvin clips is included.
* Hi / Lo limit setting.
* Hold function.
* Backlight function easy readout.
* Built-in over-input and low battery indications.
* RS232 / USB computer interface.
* Power supply :
1. 600 m 6 60 , 600 , 6 K :
DC 1.5V ( UM-3/AA ) battery x 8 PCs.
2. 60000 u : DCV power supply via
external AC/DC adapter, 90-260ACV/DC
adapter is the standard accessory.
* Ideal for measuring the resistance of
components precisely.
* Ideal for testing protective conductors, lightning
conductors and welded points.
* Good / Fail set-function for input quality control.
* Especial " CALCULATE " function to measure
cable/wire length.
* Optional USB cable, USB-01.
* Optional data acquisition software,
SW-U801-WIN.
* Optional Excel data acquisition software,
SW-E802.
