peristaltic pump adopts brushless DC motor. It has features of high output torque, low vibration, high efficiency. It can drive double pump heads. It accepts many pump heads and delivers flow rate from 0.07to 1140mL/min. The speed can be adjusted
manually or automatically through external control.
Speed 1 to 300rpm,
Speed precision 1rpm
Speed control Rotary encoded switch
Display 3-digit LED displays current speed
Power supply AC 90V - 260V 50/60Hz
Operating condition Temp. 0 to 40°C
Dimensions (LxWxH) 285x207x180 (mm)
Drive weight 3.6kg
Power consumption < 48W
IP rating IP 31
