Oscillator sinusoidal wave oscillator
Frequency 1592 Hz ±1% for –10 to +55°C
Acceleration 10 m/s² RMS
±3% for 10 to 40°C
±5% for –10 to +55°C
Velocity 10 mm/s RMS
±4% for 10 to 40°C
±6% for –10 to +55°C
Displacement 10 μm RMS
±5% for 10 to 40°C
±7% for –10 to +55°C
Maximum Load 70 g
Including:
VP-53AMounting Stud, M6
VP-55LMounting Stud, M6 to 10-32 UNF
Mounting base and adapter M6/M3
Soft Protection Case
Instruction Manual VE-10
Battery, IEC type 6LR61
