Specifi cations Range
Source Output 0 to 24mA current for loads up to 1000 ohms (-25% to 125%); Output 0 to 20V (PRC15 only)
Measure 0 to 50mA current signal (-25 to 230%); 0 to 19.99V (PRC15 only)
Power/Measure Provides power (24VDC) to loop & measu
Input/Output Ranges and Displays Resolution
0 to 19.99mA 0.01mA
0 to 24.0mA 0.1mA
0 to 1999mV 1mV
0 to 20.00V 10mV
Accuracy 0.01% ±1 digit
Meter Dims (LxWxH) 6.3" x 3.2" x 1.7" (159 x 80 x 44mm)
Meter Wt 8.2oz (232g) - not including battery weight
- 0 to 24mA (-25 to 125%)
- 0 to 20V DC calibration source
Each meter includes test
leads, alligator clips,
100V-240V AC Universal
Adaptor with 4 plugs, six
1.5V AA batteries, and
hard carry
