with grip, integrated atmospheric pressure sensor for automatic atmospheric pressure
compensation, and ALMEMO® D6 plug
Sensor connector Plug connection
Grip with socket, integrated electronics
Dimensions: Diameter 20 mm
Length 245 mm
Measuring principle non-dispersive
infrared (NDIR) technology
Sensor 2-beam infrared measuring cell
Measuring range 0 to 5000 ppm
Accuracy ±(50 ppm +3 % of measured value)
Nominal conditions +25 °C, 1013 mbar
Temperature dependence typical 2 ppm CO2 / K
in range 0 to +50 °C
Response time <195 seconds
Operative range -40 to +60 °C / 0 to 95 % RH
(non-condensing)
Measuring interval Moving average 165 seconds
(= 11 current values of 15 sec.)
