● LCD screen shows temperature, Max. temperature up to
500°C
● 10-inch glass ceramic work plate provides excellent
chemical-resistant performance and most efficient heat
transfer
● External temperature control is possible by
connecting the temperature sensor (PT 1000) with an
accuracy at ±0.2°C
● The “HOT” warning will flash if the work plate temperature
is above 50°C even when the hotplate is turned off
● Heating temperature: room temperature ~ 500°C.
● Data connector : The SD card also records the
instrument’s running data in real time.
● Timing function: the running time of the instrument can
be set.
Work plate Dimension [W x D] 254x254mm
Work plate material Glass ceramic
Heating position 1
Heating temperature range Room Temp.-500°C, increment 1°C
Temperature control accuracy ±1°C (<100°C)±1%(>100°C)
Safety temperature 540°C
Temperature,time display LCD
Timer function 1min-99h59min
Temperature display accuracy ±0.1°C
External temperature sensor PT1000 (±0.2°C)
“Hot” warning 50°C
Protection class IP21
Power 1400W
Heating output 1350W
Voltage Frequency 100-120/200-240V 50/60Hz
Dimension [WxDxH] 328x424x138mm
Weight 7.18kg
Permissible ambient temperature & humidity 5-40°C, 80%RH
