Work plate dimensionφ135mm(5 inch)
Work plate materialstainless steel cover with ceramic
Motor typeBrushless DC motor
Motor rating input18W
Motor rating output10W
Power550W
Heating output500W
Voltage100-120/200-240V 50/60Hz
Stirring positions1
Max. stirring quantity[H2O]20L
Max. magnetic bar[length]80mm
Speed range100-1500rpm
resolution±1rpm
Speed displayLCD
Temperature displayLCD
Heating temperature rangeRoom temp.-340°C, increment 1°C
Temperature control accuracy±1°C(<100°C)
±1%(>100°C)
Over temperature protection360°C
Temperature display accuracy±0.1°C
External temperature sensorPT1000 (accuracy ±0.2)
"Hot" warning50°C
Data connectorRS232
Protection classIP42
Dimension[WxDxH]160×280×85mm
Weight2.8kg
Permissible ambient temperature and humidity5-40°C, 80%RH
