Optical System - Colour Corrected Infinity Optical System (CCIS®)
nosepiece - Reversed quintuple, coded
Illumination - Interchangeable 3W LED / 30W halogen - LMS (Light Management System)
Koehler - Full
Objectives - 4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm),
100X/1.25/S-Oil (WD 0.16mm)
Objective mounting thread - W 4/5" x 1/36" (RMS standard)
Stage - Compact and rackless stage
Stage size (mm) - 185*145
Travel range X&Y (mm) - 75*50
Connectivity - HDMI, USB 2.0 for external Devices (x2), Wi-Fi, RJ-45
Accessories included - Blue filter, immersion oil 5ml, power cord, dust cover, allen key, spare HAL bulb
and LED module
Dimensions L x W x H (mm) - 282x210x370
Weight (Kg) - 8.8
