Max. Load(kN) 1000
Load Accuracy Class 1/ Class 0.5(optional)
Load Range 2%~100%FS
Load Resolution 1/350000
Deformation Measurement Range 2%~100%FS
Deformation Accuracy ≤± 1%/0.5
Displacement Resolution 0.001mm
Displacement Error ≤±0.5%
Testing speeds (mm/min) 0.1~85
Max. Piston Stroke(mm) 200
Max. Tension Test Space(mm) 950
Max. Compression Test Space(mm) 700
Column Effective Spacing(mm) 560
Clamping Method Hydraulic Automatic Clamp
Flat Specimen Clamping Width(mm) 100*100
Compression Plate Size Φ 160mm
Bending Roller Distance 450mm
Width Of Bending Rollers 120mm
Power Supply 3-phase, AC380V, 50Hz (Can Be Customized)
Overall Dimensions (L*W*H: mm) 830*720*2155
Weight(kG) 2350
