Max. Load(kN) 2000
Structure Six columns (4 columns and 2 screws)
Control Way Constant stress uniform deformation constant displacement three closed
loop control and program control dealing
Load Accuracy Class 1/ Class 0.5(optional)
Relative error of reading ≤±1%/ ±0.5%
Load Range 2%~100%FS
Load Resolution 1/500000
Deformation Measurement Range 2%~100%FS
Deformation Accuracy ≤± 1%/0.5
Displacement Resolution 0.001mm
Displacement Error ≤±0.5%
Testing speeds (mm/min) 0.1~70
Max. Piston Stroke(mm) 250
Max. speed of piston without load (mm/min) 70
Max. speed of beam adjustment (mm/min) 350
Max. Tension Test Space(mm) 1250
Max. Compression Test Space(mm) 850
Column Effective Spacing(mm) 800
Diameter of column (mm) φ100
Clamping Method Hydraulic Automatic Clamp
Round insert (mm) Φ15-Φ30,Φ30-Φ55,Φ55-Φ70
Flat insert (mm) 10-40, Optional: 40-70
Flat Specimen Clamping Width(mm) 150*120
Compression Plate Size Φ 160mm
Bending Roller Distance 450mm
Width Of Bending Rollers 120mm
Power Supply 5kW, 3-phase, AC380V, 50Hz / 220V/60Hz(Can Be Customized)
Dimension of load frame (mm) 1100×850×3135
Dimension of power package (mm) 1200×680×750
Weight of machine (kG) 5830
