Testing Force
62.5Kgf, 100Kgf, 125Kgf, 187.5Kgf, 250Kgf,
500Kgf, 750Kgf, 1000Kgf, 1500Kgf, 3000Kgf
612.9N, 980N, 1226N, 1839N, 2452N,
4900N, 7355N, 9800N, 14700N, 29400N
Testing Range (8-650) HBW
Hardness Display Check the Table of Brinell Hardness Scale
Magnification of Microscope Analogue 20x Microscope
Max. Height Of Specimen 225mm
Instrument Throat 135mm
Power Supply AC220V/50Hz ; AC110V/60Hz
Dimension (LxWxH) 893 x720 x747mm
Gross/Net Weight 160Kg/130Kg
Execution Standard ISO 6506, ASTM E10-12, JIS Z2243, GB/T 231
