ifications:
Speed 1.0 to 100rpm, reversible
Speed resolution 0.1rpm
Speed control
Rotary encoded switch coupled with
membrane keypad
Display
128x64 graphic LCD displays current
running status
External control
start/stop & cw/ccw control,
o to 5V, 0 to 10V, & 4 to 20mA
speed control
Power supply
AC 220V ± 10% 50Hz/60Hz(standard)
Power consumption <50W
Operating condition
Temperature 0 to 40°C
Relative humidity < 80%
Drive Dimensions(LxWxH) 202x160x239 (mm)
Drive weight 5.34kg
IP rating IP 31
