Max temperature: 500 deg.C
Heat-up time to max(min):120
Recovery time to max (min):20
Untenal size: 610x610x610 HxWxD(mm)
External Size: 1160x1030x1280 HxWxD(mm)
Shekves fitted/accepted:3/4
Volume (liters):220
Max power (W):4500
Weight:179kg
● Digital PID temperature control using 301 controller
including over- temperature protection.
● Rear mounted fan & side air guides give horizontal
‘airflow’.
● Manual gas control via needle valves & flowmeters
(nickel brass).
● Copper pipe-work with brass flow-meter & solenoid valves .
● Single side hinged door, with metal heat seal & rubber gas tight seal, closed using none slam lever switch.
● Suitable for continuous operation (see options*).
