Mould Diameter Ф22mm, Ф25mm,Ф30mm,Ф40mm (Choose one)
Cavity Height 115mm, effective 60mm
Heating Power Ф25mm/Ф30mm 1.2W; Ф40mm 1.6kW
Pressure Mechanical pressure, 130bar
Electromotor Power 120W
Heating Temperature 50~180℃
Heating Time 0~8min
Hold Time 30s~60min
Cooling Time 0~8min
Cooling Method External water source cooling
Power Supply 220V, 50Hz,10A
Dimensions 463×402×430mm
Net Weight 50kg
