Analytical method: infrared absorption, thermal conduction
Carbon measuring range: 0.02%~100%
Hydrogen measuring range: 0.02%~50%
Nitrogen measuring range: 0.008%~100%
Repeatability: Cad≤0.5%, Had≤0.15%, Nad≤0.08%
Analysis time for single sample: ≤5min.
Combustion furnace temperature: 950 ±5 . ℃ ℃
Reagent furnace temperature: 850 ±5 . ℃ ℃
Reduction furnace temperature: 700 ±5 ℃ ℃
Range of sample weight: 75~105mg, the proposed weight is 100mg.
Maximum power: 4.5kW.
Number of placed samples: 34 samples can be placed consecutively at once.
