* Auto-range and multi-function.
* Insulation measurement ranges :
1. 4/40/400/4000 M ohm, auto range ( 250 V,
500 V, 1000 V ).
2. 4/40/400 M ohm, auto range ( 100 V ).
* Built-in the ACV & DCV & OHMS function :
DCV ( 600.0 V ), ACV ( 600.0 V ),
OHM ( 400.0 ohm, 4,000 ohm, auto range ).
* CAT III 1000V.
* Automatic zero adjust & automatic circuit
discharge.
* Lock & Test functions, safety and easy
operation.
* Precision resistance measurement with autorange,
useful for measuring low resistance
value such as motor windings, relay coils etc.
* A continuity beeper is equipped in OHM range.
* Battery operating easily to carry with
user.
* RS-232/USB computer interface.
* Powered by DC 1.5 V ( UM-3/AA ) X 8
batteries.
* Optional USB cable, USB-01.
* Optional data acqusition softwares,
SW-U801-WIN, SW-E802.
