Measurement Range0.006″ (140 µm) up to 1.10″ (28 mm)
Resolution14(7) µm for parallel and 0.4375 µm for USB interface
Repeatability14 µm for parallel and 3 µm for USB interface
Response Time0.391 ms
Non-Linearity0.1%
Power12 to 24VDC / 170mA or USB powered
Logic Levels0V (logical “O”) and 5V (logical “1”)
Connections2×10 pin double-row header, USB mini B connector
Interface (I/O)Parallel binary (5V logic), USB
IndicatorsGreen LED = Sensor ON ; Blue LED = Object Present
Data Format11 (12) bit parallel, USB
Data Range0 up to 2000 (4000) pixels
Overall Dimension3.85″ x 2.80″ x 0.85″ (97.8 mm x 71.1 mm x 21.6 mm)
Wight5.9oz (170 g)
