Test Force N:
0.098, 0.246, 0.49, 0.98, 1.96, 2.94,4.90, 9.80
Indentation Measurement: Mechanic Micrometer
Loading Control: Automatic (Loading, Dwell,Unloading)
Magnification of Microscope: 10X/40X
Magnification on of Eyepiece: 10X Analogue Eyepiece
Dwell Time:Adjustable 5-60s
Measuring Range:1HV-3000HV
Analogue X-Y Range: 25 x25mm
IlluminationAdjustable Halogen light-source
Max. Height of Specimen90mm
Standards: ISO6507,ASTM E92,JIS Z2244,GB/T4340
