Data Transmission SMS & Ethernet
Cinterion MC55i GSM Module 850/900/1800/1900MHz
RJ45 Port Baud Rate 10/100M
Enclosure Metal
Power Input DC 9~15V or AC 90~260V
2Ah Rechargeable Battery Backup Max. 7 days operation backup
AC or Battery Status Alert Al
Alarm Input / Relay Output 4/4
Analog Channels 6
8 x Temperature Sensors 8 x Submersible (-55~125°C) Steel Housing, 2 meter
Extendable up to 100 meter sensor cable
1 x Humidity Sensor o ~ 100% RH, ±3% RH
Built-in 5VDC output to sensors Direct tempera
Data Upload Interval Programmable (1 minute ~ 24 hours)
Data Upload On Schedule / Manual Request / Alarm Triggered
Internal Memory 4MB
Max. Logged Data 30000 records
Setup Software Local (RS232 or Ethernet) & Remote (optional GSM Modem)
Optional Sof
