Free operator torque controller ( on-line )
Legal weighing control suitable in option
Secure seal test suitable ( automatic bubble point control )
Using by touch screen
Measures in opening and closing directions
Measuring range: 00.00 to 99.00 Kgf.cm
6 measuring cycles: Torque closing / Reach position / Release + break / Release + break + over screw / Non-destructive test /– MORE ON REQUEST
Units: Kgf.cm / Inch.lbs / daN.cm / N.cm / N.m
Rotating angle & speed adjustable under certain cycle
Accuracy: ± 0.5 % of full scale
30 products memory
10 thresholds (limits) option
10 operators memory
Configuration by protected password (administrator)
Memorization up to 9999 measures
Dynamic display: statistics / hour / date
Display: product name / operator / batch N° / line N°
1 RS232 output and 1 printer output (software & printer)
Language: English / French / Spanish
Delivered with calibration certificate ASTM/ NIST/COFRAC/ DKD ENAC / UKAS
Easy-fast selector for cycles
Customized cycles
Special pneumatic chuck available
Auto-mode
Special auto mode with head number – filler storage
Special multi format system for both bottle and preform
Dynamometric system
110 / 230 V – 50/60 Hz
Automated part:
Safety door
Automatic zero before restarting cycle
Settable height of column for all samples
Mechanical specifications:
Stainless steel Frame
Choice of measuring chucks: Beverage / Cosmetic / Pharmacy
Dimensions: 1090 (L) x 710 (W) x 1120 (H) mm
Weight: 120 kg
