Metall Stage Size 404×228mm
Glass Stage Size 260×160mm
X,Y,Z‐axis Travel 200×100×100mm
X,Y,Z‐axis Resolution 0.0005mm
► Infinity optical system;
► Optical Magnification:20×‐500×;Digital
magnification:170×‐1700×;
► Trinocular, Inclination of 30°,Interpupillary
distance 55‐75mm;
► High eye point,Wide field WF10×/22;
► Long working distance;Quintuple(Frontward
ball bearing inner locating);
► Coaxial optical fiber lighesourse:1500W;
► Plan Archromatic objectives; 2×/0.055;
5×/0.14; 10×/0.28; 20×/0.42;
► Multi function Data process system DRO
DP300 and QM2.0 software
