Pump head: PFH01(microliter pump head) , PFH02 (milliliter pump head)
Tubin: Silicone tubing and tubing kits
Fillining volume: luL— 99.99L
Fillining accuracy: better than -/+1%
Filling cycle: 0-999999 (0 means unlimited)
Interval time: 0.1s - 999.9s
Back suction parameter: 0-30
Working direction: Clockwise
Calibration: Manual input calibration, balance reading calibration or online ratio calibration, with volume or mass data
Display: 7 inch touch screen, Chinese or English can be set
Work mode Single channel fillinin, multi-channel fillinin with the same parameters or individual parameters
IP rating: IP32
Power supply: AC 100V-240V , 50/60Hz , 250W
Dimension (L*W*H): 548mm X245mm X 198mm (without pump head)
Weight of system: 16.1kg (without pump head)
Dimension of controller (L*W*H): 187mm X 123mm X39mm
Weight of controler: 0.6kg
