Flow Range 0.005~6000ml/min
Speed Range 0.1~600rpm
Speed resolution 0.1rpm
Dispensing volume 0.001μl~ 9999l (lt is recommended to have a minimum fill of 50μl)
Dispensing time 1 ~ 999, “0"Infinite cycle
Dispensing interval time 0.1 ~ 999.9 S/Min/H, time unit adjustable
Speed accuracy < :±0.2%
Power supply AC100 ~ 240V, 50Hz/60HZ
Power consumption < 200W
External control External control input level 5V, 12V(Standard), 24V (Optional).
External control analog 0-5V(Standard), 0-10V, 4—20mA (Optional).
Communication interface RS485 communication interface, Modbus protocol is available, D815 external control interface
Working environment Temperature 0 ~ 40°C, relative humidity < 80%
IP grade IP65
Dimension (LXWXH) 337mmx200mmx235mm
Weight 7.1kg
