Flow range: 0.006-1690 mL/min
Speed range: 0.1-350 rpm
Speed resolution: 0.1 rpm
Speed accuracy: 0.2%
Power supply: AC100-240V 50Hz/60Hz
Power consumption: <50W
External logic level control signal: 5V, 12V (standard), 24V (optional)
External analog control signal: 0-5V (standard), 0-10v, 4-20mA (optional)
Communication interface: RS485 MODBUS
Operating condition: Temperature 0~40°C; Relative humidity < 80%
IP grade: IP31
Dimensions (L x W x H): 226 x 150 x 238 mm (8.90 x 5.91 x 9.37 inch)
Weight: 5.3 kg (11.7 lbs)
