ut method PNP, NO(normal open)
Sensing direction Vertical.
Sensing distance 4 mm.
Operating voltage 10-30 VDC.
Standard Sensing object Iron 18 x 18 x 1 mm.
Current consumption 8 mA, no load.
Response frequency 600 Hz.
Output current 250 mA max.
Leakage current 1.1 mA.
Residual voltage 0.9 VDC.
Operating Temperature -20 to 70 蚓.
Operating Humidity 35 to 95% RH.
Wire Dimension 4.7 mm Dia. x 2 m x 3 cores.
Application * Sensor for DT-2240D
Panel Tachometer
* Position Detector.
