Rated Tripping Current Settings:
10 mA, 30 mA, 100 mA, 300 mA and 500 mA.
Phase detection and phase inversion
Test Current Duration:Approx. 140 ms (200 ms, -30%)
Operating Factor:Approx. 10% for 500 mA range,
wait approx. 10 sec between each step.
Operating Temp:0 to 50 ℃ (32 to 122 ℉)
Operating Humidity:Less than 80% RH
Dimensions: 180 x 72 x 32 mm
Includes Power cable with Plug
