Eyepiece & Objectives: Wide field WF10X(Φ20mm),PL L5X/0.12,,PL L10X/0.25,PL L40X/0.60 (spring), PL L60X/0.75 (spring),
Eyepieces tube Trinocular, Inclination of 30°, (Analyzer with field diaphragm to switch)
Coaxial coarse/fine focus system, with tension adjustable and limit
stopper, minimum division of fine focusing: 2μm.
Double layer mechanical stage
(Size:210mmX140mm,movingrange: 75mmX50mm)
Abbe condenser NA.1.25 Rack & pinion adjustable
Vertical illumination
unit
Blue filter and Ground glass
Collector for illumination with halogen lamp (With field diaphragm )
6V 20W, halogen lamp, adjustable brightness
