Load Capacity (kN) 0.1
Load accuracy Class 0.5
Testing Load Accuracy ±0.5%
Testing Load Range(FS) 0.4%-100%
Load Resolution 1/500,000FS
Deformation accuracy ≤±0.5% of 0.4%~100% of rated capacity
Position resolution(μm) 0.025
Position accuracy ±0.02mm or 0.5% of displacement (whichever is greater)
Crosshead speed range(mm/min) 0.001-500
Crosshead speed accuracy ±0.5% of set speed (zero or constant load)
Crosshead Travel(mm) 772
Max. Tensile Testing Space(mm) 600/ 800 (height model)
m Max. Compression Testing Space(mm) 600/ 800 (height model)
Compression Platen(mm) Ø98
Load cell
High-precision USA load cell offers high stiffness, high stability, and high
linearity Over-load protection ,lateral loading protection, Bi-direction allows
tension and compression test Self-recognition (TEDS) function, Regular
self-calibration
Power Supply AC220V±10%, 50Hz/60Hz
Overall Dimensions (L*W*H: mm) 520*400*1340
Net Weight(kG) 110
