UV lightBuilt-in drawer type UV Transilluminator 312(302)nm
Pixels size4.4μmx4.4μm
Lens (camera) 6mm, F1.2
Camera video output12-bit
Filter (camera)Optical EtBr Filter / Optical SYBR Green Filter / Yellow Amber Filter / Orange Amber Filter
*Ordered separately
Image storage * iPad and PC not included PC
Software support Window 10 / 8 / 7 (64bit & 32bit) / XP / Vista
Cabinet Pull out, sliding transilluminator
Field of view (WxL) 10.24"x8.26" (260x210mm)
Dimension (WxLxH)16.1"x15.9"x22.4" (410x405x570mm)
WeightApprox. 54.0lbs. (24.5kg)
DisplayLED indicator light
Viewing windowBuilt-in UV viewing window
Window FilterBuilt-in Viewing Window Amber Filter 560nm
Light White light (standard)
Optional accessory White Light Plate (power built-in)
Blue light (power built-in) 470nm
PC connectionUSB port
1 D analysis softwareCat. No. MBE-IMG-SW included
Saved imageMax. 16bit
