Observation angle 45°
Magnification range (standard) 0.75X--5X
Zoom ratio 1:6.7
Eyepiece N-WF, high eye-point 10X(Ø23), Diopter adjustable
Interpupilary adjustment 48mm-75mm
Height of eye point 405mm
Working distance (standard) 110mm
Weight 6.2 kg (head 1.4kg)
optionals:
N-WF 12.5X(Ø18), 15X(Ø16), 20X(Ø13)
Max. magnification: X100
Photo adapter:0.5X, 0.65X, 1X adapters available
Auxiliary ESD objectives 0.3X [WD = 301mm], 0.5X [WD = 191.8mm], 0.63X [WD = 142.7mm],
0.75X [WD = 128.6mm], 1.5X [WD = 56.3mm ], 2.0X [WD = 38.6mm]
Max. working distance 301mm
