Capacity: 5 KN (500 kgf)
Force resolution 1/10000
Travel resolution 0.005 mm
Speed 1~1000 mm/min
Motor power 400w
Speed accuracy ±0.5%
Throat depth 70mm
Motor style AC servo motor
Testing Space 140 mm
Dimensions: 50x53x100 cm, 65kg
Power supply 220 V AC
PC-Port USB
Data Sampling Rate 5K Hz
Stroke(w/o grips) 400 mm
