Projection Screen Ø300mm
Rotation Range 0°~360°
Resolution of the rotary angle 1′
Accuracy of the rotary angle 6′
Objective Magnification 10X, 20X, 50X, (Optional 100X )
Objective Visual Field Ø30mm, Ø15mm, Ø6mm, Ø3mm
Objective Working Distance 74mm, 69mm, 63mm, 41mm
Error of magnification 0.08%
Range of X‐Ycoordinate (mm) 150*100mm, 200*150mm, 250*150mm
Z ‐coordinate (Focusing)(mm) 0~100mm
Worktable Dimensions 350×240, 400×280, 450×286
Resolution 0.001mm
Image Erect
Accuracy of Instrument (3+L/75)μm
Load Capacity 10kg, 15kg, 20kg
Overall Size(mm) 410×650×1070
Transmission Lighting 24V 150W Halogen tungsten lamp
Reflecting Lighting 24V 150W Halogen tungsten lamp
Rated Voltage AC110V/220V, 50/60Hz
Mainframe Weight 90kg
