Max capacity: 5 KN (500 kgf)
Force resolution:1/10000
Travel resolution:0.005 mm
Speed:25~500 mm/min
Speed of force 500Kg:15~500 mm/min
Speed of force 1000Kg:50~500 mm/min
Testing Space:420mm
Motor power 120w
Motor style DC motor
Effective width Ø420 mm
Dimensions:97x58x150(H) cm
Power supply 200~240 V AC
PC-Port USB
Data Sampling Rate 1K Hz
Stroke(w/o grips) 800 mm
