Optical System: Single Beam
Light Source: Tungsten Lamp
Detector: Silicon Photodiode
PC Software is included
Bandwidth: 2mm
Wavelength Range 320 – 1100nm
Accuracy ±0.5nm
Repeatability ≤0.2nm
Display 0.1nm
Gyration speed 10000nm/min
Scan speed - 4200nm/min
Photometric Range -0.301 – 3A, 0 – 200%T, 0 – 9999.9C
Accuracy ±0.003A @ 0.5A, ±0.006A @1A, ±0.5%T @ 0 - 100%T
Repeatability ±0.0015A @ 0.5A, ±0.003A @1A, ±0.2%T @ 0 - 100%T
