Size Range: 0.1-780μm
Standard: ISO13320-1:1999, GB/T19077.1-2008, Q/0100JWN001-2013
Channels Number: 69
Laser:
Main: He-Ne laser (λ= 632.8nm, P>2.0MW)
Auxiliary Laser: Semiconductor laser: λ= 650nm, P>2MW
Ultrasonic: Frequency: 40KHz Power: 35W, Time: ≥1S
Agitator: Revolutions Speed: 0-300RPM (Adjustable)
Circulation: Rated Flow: 8L/min Rated Power: 10W
Sample Pool: Volume: 350mL
Optical alignment system: Full automatic optical path alignment system
Test Speed: <2mins for each time
Volume: L85cm×W39cm×H45cm
Net Weight: 40Kg
